Key features
- Insulated panels
- Dual serving hatches
- Premium interior fit-out
- 6 plug points + DB box
Specifications
1. GENERAL
- Type
- Premium Catering Trailer
- GVM
- 1750kg
- Working Length
- 3.4m or 4.0m (specify on order)
- Interior Width
- 2.0m
- Interior Height
- 2.5m
- Counter Height
- 900mm
2. TRAILER STRUCTURE
- Chassis
- Fully Galvanised Heavy-Duty Steel Frame
- Body Panels
- Insulated Composite Panels – Heat & Sound Resistant
- Floor
- Aluminium Checker Plate – Commercial Anti-Slip
- Serving Hatches
- Dual Lockable Hatches with Gas Strut Awnings
- Entry Door
- Double-Leaf Access Door with Non-Slip Steps
- Rear Stabilisers
- 4 x Corner Stabiliser Jacks
- Tow Hitch
- 50mm Ball Hitch with Safety Chains
- Exterior Lighting
- LED Exterior Lighting Front and Rear
3. KITCHEN EQUIPMENT
- Cooking Surface
- Full-Width Stainless Steel Work Surfaces – Dual Zones
- Gas Setup
- 4-Burner Gas Piping Points – Dual Cooking Zones
- Griddle Position
- Flat Top Griddle Mounting Point Included
- Fryer Position
- Double Deep Fryer Position Included
- Prep Tables
- 2 x Heavy-Duty Stainless Steel Prep Tables
- Storage
- Overhead Cabinets + Multiple Under-Counter Cupboards
- Interior Finish
- Full Stainless Steel Lining – Walls, Ceiling & Surfaces
- Extractor
- Commercial Stainless Steel Range Hood – Fitted
4. SINK & PLUMBING
- Sink
- 3-Compartment Stainless Steel Sink (Wash, Rinse, Sanitise)
- Hand Wash Basin
- Separate Dedicated Hand Wash Sink
- Fresh Water Tank
- 150L Built-In Fresh Water Tank
- Waste Water Tank
- 200L Built-In Waste Water Tank
- Water Pump
- Electric Water Pump
- Water Heater
- Hot Water Geyser – Factory Fitted
5. ELECTRICAL SYSTEM
- Power Input
- 220V Shore Power + DB Box with Circuit Breakers
- Interior Lighting
- LED Strip Lights Throughout
- Plug Points
- 6 x 220V Plug Points
- Generator
- Compatible with External Generator
6. VENTILATION & INSULATION
- Range Hood
- Commercial Stainless Steel Range Hood – Fitted
- Exhaust Fan
- High-Speed Roof Exhaust Fan – Fitted
- Roof Vents
- Additional Roof Ventilation Points
- Wall Panels
- Insulated Composite – Heat and Condensation Resistant
7. AVAILABLE UPGRADES
- Size
- Available in 3.4m or 4.0m length – specify on order
- Refrigeration
- Upright fridge or undercounter fridge installation available
- Electrical
- Solar panel system available on request
- Branding
- Custom wrap, menu boards and signage available
- Colour
- Available in White, Red, Silver or Custom
