Key features
- Electric brakes
- Double-axle
- Hydraulic ramp
- 5m loadbed
Specifications
1. GENERAL
- Type
- Car Carrier
- GVM
- 2000kg
- Loadbed Size
- 5.0m × 2.0m
- Deck Height from Ground
- Approx. 400mm
2. CHASSIS/FRAME
- Chassis Material
- 100mm x 50mm x 6mm Open Channel
- A-Frame Material
- 76mm x 38mm x 5mm Open Channel
- Construction
- Ladder frame – Heavy Extended Neck
- Corrosion Resistance
- Painted 2K Duco
3. BODY/DECK
- Size
- 5.0m x 2.0m Loadbed
- Floor Material
- 3.0mm Checker Plate Steel with Anti-Slip Grip
- Headboard
- 400mm Fixed Front Stop Bar
- Side Rails/Panels
- Low-Profile Perimeter Rails with Lashing Points
- Tailgate/Rear Gate
- None – Open Rear with Ramp
- Ramp
- 1 x Full-Width Hydraulic Loading Ramp
- Winch Mount
- Front-Mounted Winch Plate Included
- Anchor Points
- 4 x Wheel Chock Rings + 6 x Side Lashing Rings
4. AXLES/WHEELS
- Number of Axles
- 2
- Axle Type
- 1020mm, 8-Blade HD Leaf Springs
- Axle Capacity
- 1200kg each
- Wheels
- 14″
- Spare Wheel
- 14″ on the A-Frame
- Jockey Wheel
- 60mm in Front
5. COUPLER/BRAKES
- Coupler Capacity
- 2700kg
- Brakes
- Yes – Electric Over-Run Brakes
6. LIGHTING
- Type
- 12V LED Lights
7. AVAILABLE UPGRADES
- Winch
- Electric winch available on request
- Sides
- Side rail guards available on request
- Colour
- Available in White, Black, Silver or Custom
