Key features
- Hinged dropsides
- Load from any side
- Galvanised chassis
Specifications
1. GENERAL
- Type
- Dropside
- GVM
- 750kg
- Loadbed Size
- 2.5m × 1.5m
- Side Height
- 400mm
2. CHASSIS/FRAME
- Chassis Material
- 76mm x 38mm x 3mm Open Channel
- A-Frame Material
- 76mm x 38mm x 3mm Open Channel
- Construction
- Ladder frame
- Corrosion Resistance
- Painted 2K Duco
3. BODY/DECK
- Size
- 2.5m x 1.5m
- Floor Material
- 2.0mm Checker Plate Steel
- Headboard
- 400mm Fixed Headboard
- Side Rails/Panels
- Hinged Dropside Panels – Drop on All Three Sides
- Tailgate/Rear Gate
- Hinged Drop-Down Tailgate with Safety Chains
- Anchor Points
- 4 x Lashing Rings
4. AXLES/WHEELS
- Number of Axles
- 1
- Axle Type
- 1020mm, 5-Blade Leaf Springs
- Axle Capacity
- 1000kg
- Wheels
- 14″
- Spare Wheel
- 14″ on the A-Frame
- Jockey Wheel
- 60mm in Front
5. COUPLER/BRAKES
- Coupler Capacity
- 1500kg
- Brakes
- No
6. LIGHTING
- Type
- 12V LED Lights
7. AVAILABLE UPGRADES
- Sides
- Mesh inserts available on request
- Axles
- Upgrades available on request
- Colour
- Available in White, Black, Green or Grey
