Key features
- Removable mesh sides
- No license required (under 750kg)
- Galvanised chassis
Specifications
1. GENERAL
- Type
- Multi-Purpose / Utility
- GVM
- 750kg
- Loadbed Size
- 2.0m × 1.2m
- Side Height
- 500mm
2. CHASSIS/FRAME
- Chassis Material
- 76mm x 38mm x 3mm Open Channel
- A-Frame Material
- 76mm x 38mm x 3mm Open Channel
- Construction
- Ladder frame
- Corrosion Resistance
- Painted 2K Duco
3. BODY/DECK
- Size
- 2.0m x 1.2m
- Floor Material
- 2.0mm Checker Plate Steel
- Headboard
- 500mm Fixed Headboard
- Side Rails/Panels
- Removable Mesh Sides on Pin System
- Tailgate/Rear Gate
- Drop-Down Tailgate with Safety Pins
- Anchor Points
- 4 x Lashing Rings
4. AXLES/WHEELS
- Number of Axles
- 1
- Axle Type
- 850mm, 5-Blade Leaf Springs
- Axle Capacity
- 1000kg
- Wheels
- 13″
- Spare Wheel
- 13″ on the A-Frame
- Jockey Wheel
- 50mm in Front
5. COUPLER/BRAKES
- Coupler Capacity
- 1500kg
- Brakes
- No
6. LIGHTING
- Type
- 12V LED Lights
7. AVAILABLE UPGRADES
- Sides
- Solid steel panels available on request
- Axles
- Upgrades available on request
- Colour
- Available in White, Black, Green or Grey
