Key features
- 3m loadbed
- Multiple tie-down points
- Reinforced deck
Specifications
1. GENERAL
- Type
- Flatbed
- GVM
- 1500kg
- Loadbed Size
- 3.0m × 1.7m
- Deck Height from Ground
- 500mm
2. CHASSIS/FRAME
- Chassis Material
- 76mm x 38mm x 5mm Open Channel
- A-Frame Material
- 76mm x 38mm x 5mm Open Channel
- Construction
- Ladder frame
- Corrosion Resistance
- Painted 2K Duco
3. BODY/DECK
- Size
- 3.0m x 1.7m
- Bed Height
- 500mm from Ground
- Floor Material
- 2.5mm Checker Plate Steel – Reinforced Cross Members
- Headboard
- None
- Side Rails/Panels
- None – Open Flatbed
- Tailgate/Rear Gate
- None
- Anchor Points
- 6 x Lashing Rings on Perimeter
4. AXLES/WHEELS
- Number of Axles
- 1
- Axle Type
- 1020mm, 8-Blade HD Leaf Springs
- Axle Capacity
- 1600kg
- Wheels
- 14″
- Spare Wheel
- 14″ on the A-Frame
- Jockey Wheel
- 60mm in Front
5. COUPLER/BRAKES
- Coupler Capacity
- 2000kg
- Brakes
- Yes
6. LIGHTING
- Type
- 12V LED Lights
7. AVAILABLE UPGRADES
- Sides
- Mesh or dropside sides available on request
- Ramp
- Loading ramp available on request
- Colour
- Available in White, Black, Green or Grey
