Key features
- Heavy-duty 1500kg payload
- Double-axle option
- Construction-grade
Specifications
1. GENERAL
- Type
- Multi-Purpose / Heavy Commercial
- GVM
- 1500kg
- Loadbed Size
- 3.0m × 1.6m
- Side Height
- 600mm
2. CHASSIS/FRAME
- Chassis Material
- 76mm x 38mm x 5mm Open Channel
- A-Frame Material
- 76mm x 38mm x 5mm Open Channel
- Construction
- Ladder frame
- Corrosion Resistance
- Painted 2K Duco
3. BODY/DECK
- Size
- 3.0m x 1.6m
- Floor Material
- 2.5mm Checker Plate Steel
- Headboard
- 600mm Fixed Headboard – Built from 50mm Square Tube
- Side Rails/Panels
- Heavy-Duty Removable Mesh or Solid Steel Sides
- Tailgate/Rear Gate
- Drop-Down Rear Gate with Safety Chain
- Anchor Points
- 6 x Lashing Rings
4. AXLES/WHEELS
- Number of Axles
- 1 (Double-Axle Available)
- Axle Type
- 1020mm, 8-Blade HD Leaf Springs
- Axle Capacity
- 1600kg
- Wheels
- 14″
- Spare Wheel
- 14″ on the A-Frame
- Jockey Wheel
- 60mm in Front
5. COUPLER/BRAKES
- Coupler Capacity
- 2000kg
- Brakes
- Yes
6. LIGHTING
- Type
- 12V LED Lights
7. AVAILABLE UPGRADES
- Sides
- Full dropsides or solid panels available on request
- Axles
- Double-axle upgrade available on request
- Colour
- Available in White, Black, Green or Grey
